Product detail:
Features of automatic bottle filling and capping machine
1. Electronic and pneumatic routs are protected by a control box ( to keep them from humidity and short circuit caused by water from cool air)
2. Equipped with security door and protection cover, 3 color alarm lamp(Safe design, intelligent alarm)
3. Poly carbonate for protection cover (transparent,pressure bearing , and can be cleaned by alcohol)
4. Equipped with no –drip nozzles and plate to collect the dripping liquid ( avoid dripping liquid polluting the containers)
5. Equipped with horizontal position bottle blocker ( to keep the nozzles accurately aim at the bottle neck )
6. 304 frame, parts touching product is made of USU316L, manufactured by Taiwan producer
7. Unique design for capping, can make sure every bottle capped well, espeically suitable for glass bottle with metal caps.
Parameter
program | automatic bottle filling and capping machine |
Filling head | 4.6.8 etc(optional) |
Filling volume | 50-300ml, 200-1000ml etc(customized) |
Filling speed | 2000-3000bph(based on 6 nozzles) |
Filling precision | ≤±1% |
Power supply | 380V 50/60HZ |
Power supply | ≤1.5kw |
Air pressure | 0.6-0.8MPa |
Net weight | 400kg |
