automatic liquid filling machine
1.descriptions
this machine is a 3 in 1 machine,include washing the bottle,filling water into the bottles and then capping. if you need,we can supply the whole line. (bottle making machine,water trement system,washing,filling,capping 3 in1 machine,label machine,packing machine and so on)
2.technical parameters
Model: | CGF16/12/6 | CGF18/18/6 | CGF24/24/8 | CGF32/32/12 | CGF40/40/12 | CGF48/48/12 |
Production Capacity:500ml(B/h) | 4000 | 6000 | 10000 | 14000 | 17000 | 20000 |
Suitable Bottle Standard:(mm) | 150-300 | 150-340 | 150-340 | 150-340 | 150-340 | 150-340 |
Suitable Cap Standard:(mm) | φ50-φ110 | |||||
Filling Pressure:(Mpa) | 0.2-0.3 | |||||
Filling Model: | by Gavity | |||||
Power:(KW) | 3.13 | 3.84 | 3.84 | 5.6 | 6.3 | 7.3 |
Filling Temperature: | Room Temperature | Room Temperature | Room Temperature | Room Temperature | Room Temperature | Room Temperature |
Overall SizeL×W×H(mm) | 2400×1670 ×2350 | 2470×1970 ×2350 | 2865×2170 ×2350 | 3700×2570 ×2350 | 3800×2950 ×2400 | 4500×3400 ×2400 |
Total Weight:(kg) | 2500 | 3000 | 4000 | 5000 | 6000 | 7000 |
washing head
filling head
capping head
Any question about the machines ,please contact with us.And welcome to royal machine!
