Brand:aa
Product detail:
Plastic Crusher Machine
1) Suitable for recycle of all kinds of plastic bottles, containers, pellicle, plastics sheets,spurs from injection molding machines and extrustion parts.
2) The cutter stand is designed as a step-shearing style, which can resolve the force bored by cutting, and increase the force of cutting greatly.
Specification
| Crushing | Return | Crushing | Rotary | Stationary | Power | Dimension | Weight | ||
| Model | chamber(MM) | Diameter(MM) | ability(KG/H) | Blade (PCS) | Blade(PCS) | (KW) | HP | (CM) | (KG) | |
| PC180 | 185*150 | 6 | 100-150 | 9 | 2 | 2.2 | 3 | 76*47*92 | 160 | |
| PC250 | 250*220 | 6 | 130-200 | 6 | 2 | 4 | 5 | 97*70*106 | 300 | |
| PC300 | 320*240 | 8 | 220-300 | 9 | 2 | 5.5 | 7.5 | 115*820*110 | 370 | |
| PC400 | 420*275 | 10 | 350-500 | 12 | 2 | 7.5 | 10 | 125*910*134 | 500 | |
| PC500 | 520*300 | 10 | 450-600 | 15 | 2 | 11 | 15 | 141*102*150 | 650 | |
| PC600 | 620*340 | 12 | 600-800 | 18 | 4 | 15 | 20 | 181*120*177 | 900 | |
| PC700 | 720*345 | 12 | 800-900 | 21 | 4 | 15 | 20 | 182*127*176 | 1000 | |
| PC700 | 720*345 | 12 | 800-900 | 21 | 4 | 22 | 30 | 182*127*176 | 1000 | |
| PC800 | 773*460 | 12 | 800-1000 | 24 | 4 | 22 | 30 | 240*170*220 | 1860 | |
| PC800 | 773*460 | 12 | 800-1000 | 24 | 4 | 30 | 40 | 240*170*220 | 1860 | |
| PC800 | 773*460 | 12 | 800-1000 | 24 | 4 | 37 | 50 | 240*170*220 | 1860 | |
| PC900 | 870*460 | 12 | 1000-1200 | 27 | 4 | 22 | 30 | 240*180*220 | 2000 | |
| PC900 | 870*460 | 12 | 1000-1200 | 27 | 4 | 37 | 50 | 240*180*220 | 2000 | |
| PC900 | 870*460 | 12 | 1000-1200 | 27 | 4 | 45 | 60 | 240*180*220 | 2000 | |
