Brand:aa
Product detail:
Plastic Extruder Machine for Pipe
PVC PIPE EXTRUSION
CPVC PIPE EXTRUSION
plastic filament extruding machine
PVC Plastic Extruder Machine
Configuration:
It contains hot and cool mixing unit ,conical twin screw extruder, pipe mould, vacuum calibrating tank, cooling tank, haul-off machine , cutting machine and stacker.
Application:
It is mainly used to produce PVC water pipe, PVC drainage pipe, PVC electrical conduit pipe and so on.
Characteristic:
Pipe range | 20-63mm single | 20-63mm dual | 75-160mm | 110-315mm | 315-630mm |
Extruder | SJZ51/105 | SJZ65/132 | SJZ80/156 | SJZ80/156 | SJZ92/188 |
Extruder power | 18.5kw | 37kw | 37kw | 55kw | 110kw |
Extrusion capacity | 120kg/h | 250kg/h | 250kg/h | 360kg/h | 800kg/h |
Max. Production speed | 12m/min | 10m/min | 6 m/min | 3 m/min | 1.2m/min |
Click for original picture
