Product detail:
woodworking cnc router machine SM-1325B (1300*2500mm)
kind tips:1ft=304.8mm
Specifications and parameters:
Model | SM-1325B |
X Y working area | 1300 x 2500 mm |
Feeding height | 200 mm |
Structure | Whole thick Steel cast tube. Gantry moving type |
Motor | Stepper motor : 86BYG450B |
Driver | BIG DRIVER : Leadshine ND2278 |
X Y Z | X Y Gear rack straight tooth type, Z ball screw X Y Z ----- Square orbit |
Spindle power | 3kw water cooling (2-12.7mm shank bits) |
table | vaccum absoption table(with vaccum pump) |
Dust absorption | 2.2kw |
Control system | Mach3 (Parrallel port) |
Working Speed | 0-10,000mm/min |
Working precision | 0.05mm/300mm |
Command code | HPGL, G code |
Repeatability | 0.01 mm |
Power | AC220V/380v ±10% / 50~60Hz |
Compatible Software | Type3/Artcam/UG/Pro-E/Mastercam/Ucancam V8 etc |
parts:
1.taiwan Hiwin linear square guide way, double four ball slider, loading capacity, smooth operation, high precision, long lifetime.
2.Dust collector can help you to suck the sawdust.
3.more stable structure--six legs
4. Vacuum table with 6 vacuum zones, can be effective for the adsorption of different size plates.
Absorb the wood into the table,and fixing it to prevent the wood sliding.
