Brand:aa
Product detail:
professional wood cnc router carving machine for wood furniture DM-M1325
1.The lathe bed is cast iron wholly. High-rigidity ,firmness, without deformation
2.Square guide rails more wear uniform load carrying capacity greater
3. vacuum partition table, you can make more smooth workpiece. And each hole with iron absorption gauze to prevent clogging adsorption channels.
4.Stepper motor run more smoothly, you can automatically make knives, carving more precise.
5.Move Column Gantry, more stable
6.Four-row ball bearing self-lubricating block, you can reduce friction and longer life
7.Dust-proof structure, can effectively improve the running accuracy
8.Breakpoint specific memory, power outages continued carving.
9.Well Compatibility, compatible Type3/ Artcam/ Castmate/Wentai, and so on a variety of CAD/CAM design software
application:
Applicable materials: wood, bamboo, organic glass, crystal, plastic,garments, paper, leather, rubber, ceramic, glass and other nonmetal materials
Applicable industries: advertisement, gift, shoes, toys, computers,garments, model cutting, building, packaging, paper industry
NO. | Description | Parameter |
1 | X,Y,Z Working Area: | 1300x2500x200mm |
2 | Table Size: | 1360×2940mm |
3 | Positioning Accuracy | ±0.05mm |
4 | X,Y,Z repositioning Accuracy | ±0.05mm |
5 | Table Surface: | T-slot table (Option: Vacuum and T-slot combined ) |
6 | Frame: | Welded structure |
7 | X, Y Structure: | Rack and Pinion Drive, Hiwin Rail Linear Bearings |
8 | Z Structure: | HIWIN Rail Linear Bearings and Ball Screw |
9 | Max. Power Consumption: | (Without spindle) 4.2Kw |
10 | Max. Rapid Travel Rate: | 30000mm/min |
11 | Max. Working Speed: | 20000mm/min |
12 | Spindle Power: | 3.0/4.5/6/7KW |
13 | Spindle Speed: | 0-24000RPM |
14 | Drive Motors: | stepper system ( Servo optional) |
15 | Working Voltage: | AC380V/50/60Hz,3PH |
16 | Command Language: | G code |
17 | Operating System: | Ncstudio System(options:DSP /Mach3 PC Software) |
18 | Computer Interface: | USB |
21 | X,Y Resolution | <0.01mm |
22 | Software Compatibility: | Type3/UcancameV9 software, (Option: Artcam software) |
23 | Running Environment Temperature | 0degree - 45 degree |
24 | Relative Humidity: | 30% - 75% |
25 | Packing Size: | 3200X1960X1870mm |
26 | N.W.: | 1200KG |
27 | G.W.: | 1500KG |
28 | Guarantee | One year from the date of commission |
29 | Optional Parts | Air cooling spindle or Water cooling spindle |
Syntec control system | ||
Dust collector | ||
Vacuum Pump | ||
Rotary system | ||
Mist-cooling system | ||
850W YASKWA/800W Panasonic Servo motors |
Guarantee & After Sales Service:
1) The machine guarantee is 1 year.
2) 24 hours technical support by phone, email MSN.or QQ.
3) Friendly English version manual and operation video CD disk.
