Product detail:
Hot sale pill machine
Application scope:
Can be used in Pharmacy, Snacks processing and other fields.
1:single punch tablet press machine
2:can press pills, candy, calcium tablet ,
3:tablet can be with any kinds of Logo design
It is small desk-top tablet press, which can press various tablets continuously by means of manual operation.
With simple structure, convenient operation, the machine has high degree of automation. It can be used for small batch or laboratory production of a variety of medical tablets, sugar tablets, calcium tablets and so on.
The machine can press varieties of small particles and coarse powder into round or irregular tablets. It is not suitable to press large granular solids, wet powder or fine powder.
Model | MG-FT-1.5 | MG-FT-5 |
Max. Pressure | 1.5T | 5T |
Max. Dia. of Tablet | Φ14mm | Φ18mm |
Max. Depth of Fill | 11mm | 15mm |
Dia. of up and down punch pole | Φ10mm | Φ10mm |
Dia. of Middle Mould | Φ28mm | Φ33mm |
Production Capacity | 3600pc/h | 2000-3600pc/h |
Main Motor Power | 0.37kw | 0.55kw |
Net Weight | 85kg | 145kg |
Overall Size (L*W*H) | 540*450*640mm | 600*500*700mm |
