Product detail:
capsule bellows pressure gauge:
1. CE, SGS, KS certificate
2. Materials, ranges, connections are available upon request.
| Product | Case Diameter (mm) | Accuracy | Measuring Range (KPa) | Conection Thread | Installation | |
| Name | Model | |||||
| Capsule Bellows Pressure Gauge | YE-60 | 60 | 2.5% | 0-1.6,2.5,4,6,10,16,25,40,60 | M14X1.5 | Bottom Connection |
| YE-75 | 75 | 1.6% | PT3/8 | |||
| YE-100H | 100 | 1.6% | M20x1.5 | |||
| YE-150H | 150 | 1.6% | ||||
| YE-100HZ | 100 | 1.6% | Back Connection | |||
| YE-150HZ | 150 | 1.6% | ||||
| Material | ||||||
| Case | Connection | Dial | Window | Element | Pointer | Movement |
| stainless steel | stainless steel | white aluminum and black mark | glass | stainless steel | aluminum | stainless steel |
| black steel | brass | white aluminum and black mark | glass | phosphor bronze | aluminum | brass |
Option Info:
Connection thread:
NPT, BSP, BSPT and other special specification
Window (lens):
Glass, acrylic, and polycarbonate lens available
Dial plate:
Single and dual scale (Psi, kPa, mbar, H2O) available
Zero adjust:
Adjustable on the dial
<img src="http://i00.i.aliimg.com/img/pb/646/467/669/669467646_309.jpg" alt="mircro bellows pressure gauge" ori-width="503" ori-height="573"><img src="http://i00.i.aliimg.com/img/pb/649/467/669/669467649_643.jpg" alt="mircro bellows pressure gauge" ori-width="450" ori-height="505">
HAKIN-25 years manufacturing experience of pressure gauges.
