Brand:aa

Product detail:

world-popular gate door receiver and remote YET412PC

 Productphoto:

1. brief introduction

Our company design and produce the M&C 412PC twelve channels wireless intellect receiving control what can provide switch signal to the twelve relay, so it can meet many requirements such as: control motor’s corotation and reversal, the connection and lock of the switch and other special control programs. This kind of wireless intellect receiving control main apply to auto door, curtain, lifting appliance, gate way, lifter, industrial control and security line

This kind of wireless receiving control is high confidentiality, large memory space, stable characteristics, low power consume and very convenience, it is unnecessary adopt the traditional wire jumper or dip switch code but only receive and store the wireless signal from the remote control, and The lost learnt control can not work if you delete the memory message of the receiving control, however it could learning again by the owner if want to obtain the right of use.

2. The way of output

1. Signal inching-1 connect 2 disconnect

2. Signal interlock- 2 connect 1 disconnect

3. Signal self-locking –1.2 disconnect

4. One way self-locking, another way inching-1.2 connect

(check the Circuit diagram for details)

3. Learning way and steps

1. Press learning key of receiver-indicate enter into the status of learning as you hear the sounds of buzzer.

2. Press any button of the remote control-indicate learning success as you hear the sounds of buzzer.

4. Delete memory message

Press the learning button of the receiver about 7 seconds until the ring of buzzer is extinguished, which indicate success to delete the memory message.

5. Main Technique Data

6. Circuit diagram for your reference
