Model

JXP50

Max Power Pm(W)

50

Max Power Voltage Vm (V)

19.1

Max Power Current Im (A)

2.6

Open-Circuit Voltage Voc (V)

22.5

Short-Circuit Current Isc (A)

2.75

Maximum System Voltage (V)

715VDC

Front Glass

High Transparency Tempered Glass,3.2mm

Junction Box

Pass the TUV Certificate PPO(black/IP65)

Output Cables

4mM2/0.9m

Frame

Anodized aluminum alloy type 6063-T5

Encapsulation Material

EVA (0.50 ±0.03mmthickness)

Back Foil

White TPT (0.32 ±0.03mmthickness)

Fixing adhesive

Silicone Sealant(White)

emperature Range(°C)

-40°C to +85°C

Max Load(Kpa)

2.4 wind load / 5.4 snow load

Temperature Range(°C)

-40°C to +85°C

1. Nominal 18V DC for standard output.

2. Cable connectors for easy installation.

3. Outstanding low-light performance.

4. Splendid aesthetic appearance and easy installation.

5. High efficiency & high stability.

6.Advanced EVA encapsulation system with TPT back sheet to improve product modules

7. Design to meet unique demand of customer.

8.25 year module output warranty.

9. Rugged design to withstands high wind pressure and snow load, easy installation.

10. Designed to comply with rigorous operating conditions, including test.
