Welcome to the world of MEAN WELL!
HLG-120H-48A
Product Pictures
Here is the detailed info for my MW HLG-120H-48A mean well original . Hope you like it.
Product Details
(AC Input Side View)
(DC Output Side View)
(Back View)
(It's paching)
Product Information
Features :
MODEL | HLG-120H-48A | |
OUTPUT | DC VOLTAGE | 48V |
RATED CURRENT | 2.5A | |
HOLD UP TIME (Typ.) | 12ms at full load 230VAC /115VAC
| |
RATED POWER | 120W | |
RIPPLE & NOISE (max.) Note.2 | 200mVp-p | |
VOLTAGE ADJ. RANGE (SVR1) | 43~53V | |
CURRENT ADJ. RANGE(SVR2) | 1.2~2.5A (Can be adjusted by internal potentiometer A type only) | |
VOLTAGE TOLERANCE Note.3 | +/-1.0% | |
LINE REGULATION | +/-0.5% | |
LOAD REGULATION | +/-0.5% | |
SETUP TIME | 2500ms,50ms at full load 230VAC/ 115VAC;
| |
INPUT | VOLTAGE RANGE | 90 ~ 305VAC 127 ~ 431VDC |
FREQUENCY RANGE | 47 ~ 63Hz | |
POWER FACTOR (Typ.) | PF>0.98/115VAC, PF>0.95/230VAC, PF>0.93/277VAC at full load (Please refer to "Power Factor Characteristic" curve)
| |
EFFICIENCY (Typ.) | 93.5% | |
AC CURRENT (Typ.) | 1.4A/115VAC 0.6A/230VAC 0.55A/277VAC | |
INRUSH CURRENT (Typ.) | COLD START 60A/ 230VAC | |
LEAKAGE CURRENT | <0.75mA / 277VAC | |
