Product detail:
Mobile Container Ramp
Manual Loading Container Ramp,Mobile Truck Ramp
1.Hand Hydraulic pump
2.Adjust Safety chain
3.Meshwork steel
4.Heavy-duty formed steel side girders
5.Collocated Brake cushion
| Model no. | Max Load Weight(mts) | PLATFORM SIZE (mm) | WORKING HEIGHT (mm) | remark | ||||||||
| A | B | C | D | E | F | G | H(MIN.) | I | J (MAX.) | |||
| DCQY 6-0.8 | 6 | 7000 | 2200 | 1000 | 300 | 10500 | 2000 | 2080 | 1000 | 800 | 1800 | no rack |
| DCQY 8-0.8 | 8 | 7000 | 2200 | 1000 | 300 | 10500 | 2000 | 2100 | 1000 | 800 | 1800 | no rack |
| DCQY 10-0.8 | 10 | 7500 | 2400 | 1000 | 300 | 11200 | 2000 | 2100 | 1000 | 800 | 1800 | no rack |
| DCQY 6-0.5 | 6 | 7000 | 2200 | 1000 | 300 | 10500 | 2000 | 2080 | 1200 | 500 | 1700 | with rack |
| DCQY 8-0.5 | 8 | 7000 | 2200 | 1000 | 300 | 10500 | 2000 | 2100 | 1200 | 500 | 1700 | with rack |
| DCQY 10-0.5 | 10 | 7500 | 2400 | 1000 | 300 | 11200 | 2000 | 2100 | 1200 | 500 | 1700 | with rack |
