Product detail:
3500lbs 12V/24V Winch For Snowplow
3500LB, WINCH SPECIFICATIONS
Rated line pull | 3500lbs(1588kgs) single line |
Motor | 1.2kw/1.4hp (12v) |
Gear reduction ratio | 153:1 |
Gear train | Differential Planetary |
Cable (Dia x L) | Ø5.4mmx10.5m |
Drum size (Dia x L) | Ø2”(51mm) x2.9”(74mm) |
Braking action | Automatic In-The-Drum |
Overall dimensions(L X W X H) | 13.4''x4.3''x4.4''(340mm X110mm X112mm) |
Mounting bolt pattern | 120mm*76mm , Ø9 |
Weight | N.W.10kg G.W.12kg |
Packing size | 410 x 350 x 210mm 1PC/CTN |
CBM | 0.03m3 |
Detail:
LINE PULL AND ROPE CAPACITY IN LAYER
Layer | Rated Line Pull lbs(kgs) | Total Rope on Drum ft(m) |
1 | 1500(680) | 6.5(2.0) |
2 | 1227(557) | 14.0(4.3) |
3 | 937(425) | 23.5(7.2) |
4 | 900(408) | 25.0(7.6) |
PULL, SPEED, AMPERES, VOLTS
Line pull lbs(kgs) | Line speed ft/min(m/min) | Current A |
0 | 10.5(3.2) | 8 |
500(227) | 9.2(2.8) | 30 |
1000(454) | 7.5(2.3) | 60 |
1500(680) | 5.2(1.6) | 90 |
