Brand:aa
Product detail:
Brief introduction
Our company is mainly engaged in exporting coal mining machinery and drilling tools. They are used in coal mining, oil, gas industries and other industries. Our products are mainly sold to the Middle East, Africa, Southeast Asia, Western Europe and other countries. We provide the best products and services for customers and aim to establish long-term and win-win cooperation.
Electric warping winch
Description of Electric warping winch
Electric warping winch we sell is in compliance with the national standard. The design of warping winch is reasonable, The materials are of good quality, The structure is advanced. The appearance of warping winch is beautiful and the size is compact, the weight is light, the hand pull force is small and parts have high strength, big tenacity, and all these make warping winch safe and durable. And the warping winches are popular at home and abroad.
Features :
1. Reliability.
2. Availability and performance.
3. Reliable and efficient designs.
4. High quality steel made.
5. Every design meets the customer’s requirements.
Main Parameter
Model | JM2 | JM3 | JM5 | JM8 | JM10 | |
Line pull capacity (kg) | 2000 | 3000 | 5000 | 8000 | 10000 | |
Wire rope average speed (m/min) | 12 | 10 | 10 | 10 | 9 | |
Wire rope(mm): | 12.5 | 15.5 | 21.5 | 26 | 30 | |
Reduction box | Type | JZQ350 | JZQ350 | JZQ400 | JZQ500 | JZQ650 |
Transmission ratio | 23.34 | 31.5 | 23.34 | 31.5 | 40.17 | |
Drum (mm) | Diameter | 273 | 325 | 406 | 500 | 550 |
Length | 480 | 520 | 645 | 900 | 1000 | |
Capacity(m) | 150 | 180 | 250 | 300 | 450 | |
motor | Type | YZ160M2-6 | YZ160M2-6 | YZ160L-6 | YZR225M-8 | YZR250M1-8 |
Power(kW) | 7.5 | 7.5 | 11 | 22 | 30 | |
Rotate speed(r/min) | 948 | 948 | 953 | 720 | 720 | |
Hydraulic Brake | YWZ-200/25 | YWZ-200/25 | YWZ-300/45 | YWZ-300/45 | YWZ-300 | |
Equipment Dimension (cm) | 142 x96 x62 | 154 x107 x70 | 185 x135 x90 | 205x275x105 | 220x190x110 | |
Weight(kg) | 630 | 680 | 1400 | 3000 | 4000 | |
