Product detail:
TianGe 2500kg hand pallet forklift
Hydraulic Hand Pallet Truck PT-BF type:
- Full hydraulic system. Bullet connection between steering shaft and pump piston. It is convenient to replace the rear wheel.
- Easy to maneuver with 210 degrees turning radius.
- Grease fitting at all pivotal points to ensure trucks long life and easy control.
- Special lowering valve to control the rate of descent and over load by-pass valve to make the trucks durable.
- Number of pump strokes -10. Lift height per stroke: 12mm.
- Reliable oil leak-proof hydraulic system.
- Option: nylon wheel, polyurethane(PU) wheel, rubber wheel single fork roller or tandem roller.
Capacity (kg) | 2,500 kg |
Total lift height H2(mm) | 200 | 190 |
Lowered fork height H1(mm) | 85 | 75 |
Height of handless H3(mm) | 431.5 | 421.5 |
Fork Length L (mm) | 1,150 | 1,220 |
Width over the forks W (mm) | 520/550 | 685 |
Steering wheel A (mm) | 200 | 180 |
Fork wheel B (mm) | 80 | 74 |
Truck Weight (kg) | 75/78 kg | 80 kg |
