2013 New Design CG430 Brush Cutter

Click for original picture
Fob Price: 80.00 USD/
MOQ: 20
Payment Terms: delivery withindays since payment
Location: China
  Ms. Maggie Liu    Contact Now 詢價
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:

Advantage of CG430 Brush Cutter :

1, Brush cutter harvesting clean, laying neatly Article Shop or stacked.
2, Harvest Never again hunched over, and the men and women of labor can be used.
3, Brush cutter is adapted to the size of the plots and mud Tian plains, hills,
terraced, triangle, etc.;
4, Brush cutter is easy to operate, and easy maintenance.

Details of CG430 Brush Cutter :



Multiple Choice of CG430 Brush Cutter :

a. pipe: length (1.65m/1.25m, ect also can be chosen), material (stainless steel/ aluminum)
b. blade: nylon type/ straight/3T/4T/8T/30T, etc
c. engine: 1E34F/T200/1E36F/1E40F-5/139F/GX35, etc. can be matched as you need
d. type: side hang/ backpack
e. packing can be made as your requirements



Specification of CG430 Brush Cutter :

Engine model

1E40F-5

Engine type

Forced air cooling, 2-Stroke, Single cylinder

Displacement

43CC

Engine power

1.45KW/7000r/min

Fuel tank capacity

1200ml

Type

Side attached type

Carburetor type

Diaphragm

Fuel ratio

gasoline/2-cycle oil mixing ratio: 25:1

Packing size

42X32X31CM

Engine packing

360*300*240mm

Shaft packing

1640*120*100mm



Application of CG430 Brush Cutter :



Package of CG430 Brush Cutter :

Notes of CG430 Brush Cutter :

In order to ensure the smooth of brush cutter during the use, you need to master a number of

points to note. The following seven points to keep in mind:

1, Familiar with the operation, carefully read brush cutter manual to know in case of an

emergency, shut down the engine in a timely manner.

2, Before using, carefully check all parts of the blade and the brush cutter is securely

connected. To replace the old and damaged blade or screw sets, in order to avoid the machine

is not running smoothly.

3, Only outdoors before starting the engine to add fuel.

4, Do not artificially adjust the governor, the engine speed is too high.

5. Should work slowly push mower to move forward, speed is not too fast.

6. Sloping mowing, not to high and sometimes low. Turn on sloping land, we must be especially

careful. Do not mow grass on steep slopes.

7, Set mower grass box, set grass box is not installed, do not use the mower.

Daily Maintenance of CG430 Brush Cutter :

(1) The maintenance of the oil.

Each time before using the lawn mower should check the oil surface, to see whether it is in the

middle of the oil gauge.

(2) Lawn mower air filter maintenance

Before every use and after use to check whether dirty.

(3) Maintenance mower carburetor and oil line

Add gasoline every call should filter filtration, and can not be put in the tank for a long time,

applications carburetor cleaner carburetor cleaner, carburetor dirty degree cleaning cycle.

We Promise:

1. Technical guidance (24 hours online tradmanager, skype, mobile).

2. Loading inform (loading port, destination port, shipping date, CBM, weight etc.)

3. Within warranty period, we will provide free parts for replacement if any problem belongs to us.

(delivery cost paid by customer).

4. After the warranty period the parts are offered at cost price

5. If you need the on-site show, welcome to our factory.

Related Models Of CG430 Brush Cutter :

Item No.

Engine model

Displacement

Blade

Type

GX35

GX35

35.8cc

Nylon cutter or metal blade

Knapsack or Side attached

431

139F

31cc

Nylon cutter or metal blade

Knapsack or Side attached

411

1E40F-6

40.2cc

Nylon cutter or metal blade

Knapsack or Side attached

328

1E36F

30.5cc

Nylon cutter or metal blade

Knapsack or Side attached

430

1E40F-5

42.7cc

Nylon cutter or metal blade

Knapsack or Side attached

330

1E36F-2

32.6cc

Nylon cutter or metal blade

Knapsack or Side attached

400

T200

40cc

Nylon cutter or metal blade

Side attached

520

1E44F-2

51.7cc

Nylon cutter or metal blade

Side attached







Looking forward to your inquiry!
