Brand:aa
Product detail:
AT Pneumatic actuator
Model | AT040-AT400 |
Angle of rotation | 0°-90° |
Pressure range (bar) | 2--8 |
Torque (Nm) | 6-15000 |
Operating temperature (°C) | -40--+150 |
1. The design of rack and pinion double-piston
2.The extruded high-quality aluminum alloy cylinder ,its longer service life and low friction coefficient.
3.Unibody design ,double acting and single acting have the same cylinder and end cap.
4.Four adjusting screws can make the actuator more accurate .
5.Position indicator consistent with VID/VIE3845,NAMUR standards.
6.The gas source interface in line with NAMUR standard.
7.All fasteners are made of stainless steel ,to enable long-term corrosion resistance.
8.The connection parts are in line with new international standards ISO5211 and DIN3337(F03-F25).
