CS2.110TA Industrial wastewater submersible motor pump

(380V)

Features

• High head, Big water flow, Large caliber, convenient and easy to use
• Special high flow design can achieve the maximum efficiency in sewage and mud
• Gary cast iron vane wheel with Ordinary Vane Wheel or Vane Wheel(A type) with tungsten alloy cutting knife available for choice
• A type wheel is easy to cut up the impurity like branches, paper, etc. and outflow it with sewage
• ITALY imported double-faced mechanical seal and oil seal to make waterproof protection
• SUS-304 stainless steel for motor housing, motor shaft and screws
• This model can add the floater control switch as optional choice

Motor Features

• Single phase
• Closed externally ventilated
• Insulation class: E
• Protection class: IP68
• Duty: continuously rated
• Motor Thermal Protector

Application

• Suitable for clean water and salt water
• Water supply and disposal, water circulation and water change for crop farming, forestry and fishery use.
• The extraction of water accumulation for basement, food factory waste water and industrial waste water, construction dewatering.
• Equipment use for aquarium, landscape waterfall, water drainage and filtration

  *Option choice:

1. Vane Wheel (A type) with tungsten alloy cutting knife;

2. With auto switch
