Introduction

Solenoid valve is closed,configurations of valve body are closed off;the thermostat (NTC) transfers a signal to actuator that will connect to power,and then open valve,input hot water or chill water to fan coil unit,if the room temperaure reaches to set-point,thermostat transfers a signal to actuator to cut off the power,and spring switch returns, valves is closed,and the hot or chill water is block to fan coil unit.Therefore,the room temperature could be controlled in the set-point through valve opened or closed.The connect type is screw between actuator and valve body.We could install the body firstly,and then actuator.HY6018 series are smart,everlasting,less noise,less space and able to work under high temperature environment

Features

1. Action method is direct action

2. Body material is stainless steel

3. Compact design,sophisticated appearance

4. Low temperature, no noise, zero leakage

5. Action to respond to rapid, high-frequency

6. Export Series, reliable quality

Technical Data

• Voltage:AC230V±10%,50/60H z
• Consumption:6VA(only when turn on/off)
• Motor:Synchronous Motor
• Operate Time:15S
• Wire Length:50cm
• Port Size:1/2"~2"
• Nominal Pressure:<=1.6Mpa
• Turn off pressure differential:<0.6Mpa(2-way)/<0.3Mpa(3-way)
• Connection:Pipe Screw Thread G
• Media:Cold/hot water or 50% ethylene glycol solution
• Media Temperature:2~94°C
• Ambient Temperature:0~60°C,no condensing
