Long Yao Brand Auto Spray Room
Feartures
1.Manufacturer,superior quality with competitive price.
2.High ventilation,intake airflow 25000m3/h,exhaust airflow
25000m3/h.High lighting.
3.Filtering effect exceed 98%.
4.Easy operate with control panel and fast delivery.
5.All our auto spray room have one year gurantee.
Products Specification
LY-8700 auto spray room | |
Inside Dimension(mm)L×W×H | 7000×4000×2800 |
Outside Dimension(mm)L×W×H | 7100×5550×3600 |
Main Door(mm)W×H | 3-folds, 3000×2700 |
Personal Door(mm)W×H | 1-fold, 800×2000 |
Wall Panels | Rock wool, tongue and groove interlock construction, thickness: 50mm |
Basement and floor | Galvanized steel assemble, height is 300mm, with adjustable bolts, complete grilles, 3 pcs ramps, 900×2000mm (W×L), with 2 pcs inclined ramps. |
Lighting | Ceiling lights:8 units×4pcs×58w; Side lights: 10 units×4pcs×20w |
Generator Setting type | Back upper intake air,Back upper exhaust air, aluminium alloy frame, coated steel. |
Intake air fan | 1×7.5KW turbo fan, direct drive,air capacity:25000m3/h |
Extract air fan | 1×7.5KW turbo fan, direct drive,air capacity:25000m3/h |
Heating system | RIELLO RG5S oil burner, heating productivity: 260000 Kcal/h, stainless steel heat exchanger, with anti-explosion hole for protection, working temperature is 80°C, pneumatic damper from spraying to baking cycle |
Filter system | Pre-filter, high efficiency filter(Ceiling filter), fibreglass filter. |
Control System | Spraying, heat spraying, baking, temperature controller, time setting, emergency stop, temperature limit controller, lighting switch, hour meter, differential pressure meter, failure alarm. |
Total Power | 18KW |
Auto Spray Room Showing
